Type of fuel |
Fuel Oil |
Heating Area |
Up to 1200
sq. ft. |
Color |
Black |
Exterior dimensions |
18"W x
18"D x 26,25"H |
Maximum input (oil #1) |
25,765 BTU
(7,5 kW) |
Maximum input (oil #2) |
19,625 BTU
(5,7 kW) |
Minimum input (oil #1) |
12,885 BTU
(3,7 kW) |
Minimum input (oil #2) |
9,480 BTU
(2,7 kW) |
Efficiency |
81,5 % |
Maximum consumption (oil #1) |
0,22
gal/hr.* (0,72 l/hr.) |
Maximum consumption (oil #2) |
0,17
gal/hr.* (0,53 l/hr.) |
Minimum consumption (oil #1) |
0,12
gal/hr.* (0,36 l/hr.) |
Minimum consumption (oil #2) |
0,09
gal/hr.* (0,26 l/hr.) |
Exhaust pipe diameter |
5" |
Type of chimney |
L-vent for
oil |
Chimney diameter |
5" |
Type of burner |
7" dia.
(yellow flame) |
Type of carburetor |
OCI / 6
positions |
Minimum clearances (Back) |
12" |
Minimum clearances (Sides) |
16" |
Minimum clearances (Corners) |
16" |
Glass surface |
Borosilicat |
Weight |
105 lbs
(48 kg) |
Warranty |
Limited 5
years warranty |
Test standard - safety |
CSA B
140-3, UL-896 |
Minimum draft required |
0,05 INWC |
|
|
Features
- Operates
without electricity
(except for the blower)
- Easy
hook-up to optional oil tank
(gravity-fed or pump)
- Cast
iron door with borosilicat glass
- Adjustable
threaded legs
- Large
cooking surface
- Yellow
flame burner with wood-fire look
- Black
finish, gold plated or brushed nickel door
- Optional
Oil tank (36.4 liters / 8 gallons)
- Optional
Pumping kit
- Optional
Anti-downdraft die cap (5" or 6") |
|
